Copper-aluminum composite finned tube heat exchangers offer excellent heat transfer efficiency with lightweight construction. The aluminum fins are mechanically bonded to copper tubes, ensuring optimal thermal contact and long-term durability.

• Tube Material: Copper (C12200 / C11000)
• Fin Material: Aluminum (1050 / 1060 / 3003)
• Fin Type: Extruded / Embedded / L-footed
• Max Operating Temperature: 250°C

Designed for aggressive environments, stainless steel finned tube heat exchangers provide superior corrosion resistance and high-temperature performance. Ideal for chemical processing, food industry, and marine applications.

• Tube Material: SS304 / SS316 / SS316L
• Fin Material: SS304 / SS316 / SS430
• Fin Type: High-frequency welded / Laser welded
• Max Operating Temperature: 800°C

Built for heavy-duty industrial applications, carbon steel finned tube heat exchangers offer exceptional structural strength and cost-effectiveness. Suitable for high-pressure and high-temperature flue gas heat recovery.

• Tube Material: Carbon Steel (A179 / A192 / A210)
• Fin Material: Carbon Steel / Galvanized Steel
• Fin Type: High-frequency welded / Spiral wound
• Max Operating Temperature: 600°C

All-copper construction finned tube heat exchangers deliver the highest thermal conductivity available. Premium choice for applications requiring maximum heat transfer efficiency with excellent antimicrobial properties.

• Tube Material: Pure Copper (C11000 / C12200)
• Fin Material: Pure Copper
• Fin Type: Extruded / Integral / Soldered
• Max Operating Temperature: 200°C

Special alloy finned tube heat exchangers utilizing nickel-based alloys, titanium, and duplex stainless steels for extreme environments. Engineered for the most demanding temperature, pressure, and corrosion conditions.

• Tube Material: Inconel / Monel / Titanium / Duplex SS
• Fin Material: Matching alloy or optimized material
• Fin Type: Laser welded / High-frequency welded
• Max Operating Temperature: 1000°C

Fully customized finned tube heat exchanger solutions designed to meet unique specifications. Our engineering team works directly with your technical drawings, dimensions, and operating parameters to deliver bespoke thermal solutions.

• Design: Based on customer drawings & parameters
• Materials: Any machinable metal or alloy
• Fin Type: All types available
• Free model selection & scheme design
