Industrial Fin-Plate Condensers

High-performance fin-plate condensers featuring copper and stainless steel tubes with aluminum and copper fin options. Our fin-plate design maximizes heat transfer surface area through tightly spaced thin metal plates mechanically bonded to the tube bundle. Each condenser is custom-engineered to your specific operating parameters, refrigerant type, and space constraints.

Available Materials: Copper Tube Stainless Steel Tube Aluminum Fin Copper Fin
Fin-Plate Construction Explained
Our condensers use a fin-plate (plate-fin) design where thin metal plates are stacked and mechanically bonded to horizontal tubes. This construction provides exceptional surface area density for efficient heat rejection in a compact footprint. Unlike shell-and-tube designs, fin-plate condensers excel in air-cooled and forced-draft applications where refrigerant vapor condenses inside the tubes while cooling air passes over the finned surface. All units are custom-designed — we do not offer standard off-the-shelf models.

Copper Tube × Aluminum Fin

Best Value · Most Popular Configuration
Copper Tube + Aluminum Fin

The industry-standard configuration offering an optimal balance of thermal performance, weight, and cost. Copper tubes provide excellent heat transfer and corrosion resistance for refrigerant flow, while aluminum fins deliver lightweight, high-efficiency air-side heat rejection. This is our most widely specified condenser type across all industries.

Tube Material Seamless Copper (C12200 / C11000)
Fin Material Aluminum 1050 / 1060 / 3003
Fin Thickness 0.12mm – 0.25mm
Fin Spacing 2.0mm – 4.5mm (custom selectable)
Max Working Pressure Up to 35 bar (tube side)
Temperature Range -40°C to +180°C
Commercial HVAC Cold Rooms Heat Pumps Refrigeration Air Dryers Chillers
Custom Engineering Per Specification View Products

Copper Tube × Copper Fin

Premium Performance · Maximum Durability
Copper Tube + Copper Fin

The premium all-copper configuration delivering superior thermal conductivity and unmatched corrosion resistance. Ideal for marine environments, coastal installations, and applications where both tube-side and air-side fluids are corrosive. Copper fins provide excellent heat transfer with enhanced structural integrity for demanding duty cycles.

Tube Material Seamless Copper (C12200 / C11000 / C70600)
Fin Material Pure Copper (C11000 / C12200)
Fin Thickness 0.15mm – 0.30mm
Fin Spacing 2.5mm – 5.0mm (custom selectable)
Max Working Pressure Up to 35 bar (tube side)
Temperature Range -40°C to +200°C
Marine HVAC Coastal Installations Food Processing Chemical Plants Offshore Platforms Corrosive Atmospheres
Custom Engineering Per Specification View Products

Stainless Steel Tube × Aluminum Fin

Chemical Resistant · High Temperature Rated
Stainless Steel Tube + Aluminum Fin

Engineered for aggressive chemical environments and high-temperature applications where copper is not compatible with the process fluid. Stainless steel tubes handle corrosive refrigerants and process fluids, while aluminum fins maintain cost-effective air-side heat transfer. Common in chemical processing and industrial refrigeration.

Tube Material SS304 / SS316 / SS316L (seamless)
Fin Material Aluminum 1050 / 3003
Fin Thickness 0.12mm – 0.25mm
Fin Spacing 2.5mm – 5.0mm (custom selectable)
Max Working Pressure Up to 40 bar (tube side)
Temperature Range -60°C to +300°C
Chemical Processing Industrial Refrigeration Ammonia Systems Petrochemical Pharmaceutical High-Temp Processes
Custom Engineering Per Specification View Products

Stainless Steel Tube × Copper Fin

Ultimate Corrosion Defense · Dual Protection
Stainless Steel Tube + Copper Fin

The ultimate corrosion-resistant configuration combining stainless steel tube-side integrity with copper fin air-side protection. Designed for the most demanding environments where both process fluids and ambient air present corrosion challenges — offshore platforms, desalination plants, and tropical coastal installations.

Tube Material SS316 / SS316L / Duplex SS (seamless)
Fin Material Pure Copper (C11000 / C12200)
Fin Thickness 0.15mm – 0.30mm
Fin Spacing 3.0mm – 6.0mm (custom selectable)
Max Working Pressure Up to 40 bar (tube side)
Temperature Range -60°C to +300°C
Offshore Oil & Gas Desalination Plants Marine Applications Tropical Installations Geothermal Systems Waste Treatment
Custom Engineering Per Specification View Products

Material Combination Selection Guide

Use the comparison table below to select the optimal tube and fin material combination based on your operating environment, fluid compatibility requirements, and budget considerations.

Configuration Thermal Performance Corrosion Resistance Temperature Rating Cost Level Best For
Cu Tube + Al Fin ★★★★★ Moderate -40°C to +180°C $$ General HVAC, Refrigeration, Chillers
Cu Tube + Cu Fin ★★★★★ Excellent -40°C to +200°C $$$ Marine, Coastal, Food Processing
SS Tube + Al Fin ★★★★☆ Excellent (Tube Side) -60°C to +300°C $$$ Chemical, Ammonia, Petrochemical
SS Tube + Cu Fin ★★★★☆ Superior (Both Sides) -60°C to +300°C $$$$ Offshore, Desalination, Geothermal
